KAWASAKI Taumelscheiben-Axialkolbenpumpe K3VL-Serie K3VL28 K3VL45 K3VL80 K3VL112 K3VL140 K3VL200 K3VL200H
Displacement 1 cm3 = 0.061 in3 Pressure 1 MPa - 145 psi Flow 1 L/min = 0.264 gpm US gallon Torque 1 Nm = 0.74 lb ft Power 1 kW = 1.341 hp Weight 1 kg = 2.205 lb The K3VL series Swash Plate Type Axial Piston Pumps are designed to satisfy the marine, mobile and industrial markets where a medium/high pressure variable displacement pump is required. Features 320 bar continuous pressure rating 350 bar peak pressure High overall effciency (>90 % Spitzenwert)Außergewöhnliche SelbstansaugfähigkeitSAE- und ISO-Montage und WelleAusgezeichnete Zuverlässigkeit und sehr lange LebensdauerHohes Leistungs-Gewichts-VerhältnisZahlreiche SteuerungsoptionenSehr reaktionsschnelle SteuerungenGeringe Pulsation und GeräuschemissionenIntegrierte Entlastungs- oder Proportional-Druckbegrenzungsventile verfügbarHochgeschwindigkeitsversion mit integriertem Laufrad (K3VL200H)
Wir liefern Komponenten von Top-Herstellern wie Bosch Rexroth und Rexroth
Indramat, Parker Hannifin, Moog, Eaton Vickers, Denison, Hawe, Sunfab, Yuken, Hydac, Kawasaki/KPM, Staffa, Voith, Sauer Danfoss, Hydro Leduc, Calzoni, Atos, Bucher, Oilgear, Tokyo Keiki, Schneider KREUZNACH, Linde, Marzocchi, Eckerle, HBM, Siemens, Schneider Electronic, Sick, Baumer, Herion, Norgren, Aventics .....
Wenn Sie an unseren Verkäufen interessiert sind, fragen Sie uns bitte an. BAILE HYDRAULIC ist Ihr netter
Partner im Bereich Hydraulik und Elektronik. Für weitere Einzelheiten besuchen Sie uns bitte
R
| KAWASAKI Taumelscheiben-Axialkolbenpumpe K3VL-Serie |
|
|
K3VL28-KARTON
K3VL28/C-1ARSM-L0
K3VL28/C-1ARSM-P0
K3VL28/C-1NRSM-L0
K3VL28/C-1NRSM-P0
K3VL28/C-1BRSM-PR24D
K3VL28/C-1NRKM-L0
K3VL28/C-1NRKM-P0
K3VL28/C-1NRKS-L0
K3VL28/C-1NRKS-P0
K3VL45-KARTON
K3VL45/B-10RKM-L0
K3VL45/B-10}RKM-P0/1-H1
K3VL45/B-10RKM-PV/1-L
K3VL45/B-10RMM-P0
K3VL45/B-10}RSM-P0/1-E0
K3VL45/B-10RSM-P0
K3VL45/B-10RSS-P0
K3VL45/B-10RTM-P0
K3VL45/B-1ALSM-PM 24 VDC
K3VL45/B-1ALSM-P0
K3VL45/B-1ALSS-L0/1-H4
K3VL45/B-1}ARKM-P0/1-E0
K3VL45/B-1ARMM-L0/1-H1
K3VL45/B-1}ARSM-P0/1-E0
K3VL45/B-1ARSM-P0
K3VL45/B-1}ARSS-L1/1-H1
K3VL45/B-1BRSM-L0
K3VL45/B-1BBLSM-PM 24 VDC
K3VL45/B-1}BBLSM-P0/1-E0
K3VL45/B-1BBLSM-P0/1-H1
K3VL45/B-1BBLTM-P0
K3VL45/B-1BBRKM-P0
K3VL45/B-1BBRSM-P0/1-E0
K3VL45/B-1BBRSM-P0/1-H1
K3VL45/B-1BBRSS-L0
K3VL45/B-1BBRTM-P0
K3VL45/B-1}BRMM-P0/1-H1
K3VL45/B-1NLSM-L0
K3VL45/B-1NLSM-P0/1-E0
K3VL45/B-1NLSS-P0
K3VL45/B-1NLTS-P0
K3VL45/B-1NRKM-L1
K3VL45/B-1NRKM-P0/1-H1
K3VL45/B-1NRMM-P0
K3VL45/B-1NRMM-L0/1-H1
K3VL45/B-1NRSM-L0
K3VL45/B-1NRSM-L0/1-H1
K3VL45/B-1NRSS-L0/1-E0
K3VL45/B-1NRSS-L0/1-}M1
K3VL45/B-1NRSS-L0
K3VL45/B-1NRSS-PN24D
K3VL45/B-1RLTM-L0
K3VL45/B-1RRTS-L0
K3VL45/B-1BBRSM-L1/1-M2 + K3VL45/B-10RKM-L1/1-M2
K3VL45/B-1BBRSM-P0 + K3VL45/B-10RSM-P0
K3VL80-KARTON
K3VL80/B-10}RKM-L0
K3VL80/B-10RKS-L1/1-L5
K3VL80/B-10RMM-P0/1-H1
K3VL80/B-10RSM-L0
K3VL80/B-10RSM-LN24D
K3VL80/B-10}RSM-P0/1-}E0
K3VL80/B-10RSS-L0/1-L1
K3VL80/B-1ALSM-PN24D
K3VL80/B-1ALSS-L0/1-H2
K3VL80/B-1ALSS-P0/1-E0
K3VL80/B-1ARMM-P0/1-L3
K3VL80/B-1ARSS-P0/1-L1
K3VL80/B-1BBLSM-PM 24 VDC
K3VL80/B-1BBLSM-P0
K3VL80/B-1BBRSM-P0
K3VL80/B-1BBRSS-L1
K3VL80/B-1BLSS-L0/1-H1
K3VL80/B-1}BLSS-L1
K3VL80/B-1BLSS-P0/1-}Q0
K3VL80/B-1}BRMM-L1
K3VL80/B-1BRMM-LM24D
K3VL80/B-1BRMM-P0/1-M4
K3VL80/B-1}BRSM-L1/1-L1
K3VL80/B-1CLSM-P0/1-}E0
K3VL80/B-1CLSM-P0/1-H1
K3VL80/B-1CLSS-L0
K3VL80/B-1CRMM-P0/1-H1
K3VL80/B-1CRSM-P0/1-}E0
K3VL80/B-1CRSM-P0/1-H1
K3VL80/B-1NLKS-P0
K3VL80/B-1NLMM-L0
K3VL80/B-1NLSM-L0
K3VL80/B-1NLSS-L0
K3VL80/B-1NRKM-P0
K3VL80/B-1NRKM-P0/1-H1
K3VL80/B-1NRMM-P0
K3VL80/B-1NRMM-L0/1-M2
K3VL80/B-1NRSM-L1
K3VL80/B-1NRSS-P0/1-}E0
K3VL80/B-1NRSS-L0/1-M1
K3VL80/B-1NRSS-L0
K3VL80/B-1NRSS-PN24D
K3VL80/B-1RLSM-L0
K3VL80/B-1RRKS-P0/1-H1
K3VL80/B-1RRSM-L0
K3VL80/B-1RRSS-P0/1-H1
K3VL80/B-1BBLSM-P0 + K3VL45/B-1NLSM-L0
K3VL80/B-1BBLSS-L1 + K3VL45/B-1ALSS-L1
K3VL80/B-1CRMM-L0/1-H1 + K3VL80/B-1NRSM-L0/1- H1
K3VL112/K3VL140
K3VL112/B-10RCM-L1
K3VL112/B-10RKS-P0/1-H4
K3VL112/B-10}RWM-L1
K3VL112/B-1ALSM-P0
K3VL112/B-1ALWS-L0
K3VL112/B-1ARMM-L1/1-S6
K3VL112/B-1}ARSM-L0/1-M1
K3VL112/B-1BBRMM-L0
K3VL112/B-1BBRWM-L0
K3VL112/B-1BLSM-P0
K3VL112/B-1BRKM-L0/1-H1
K3VL112/B-1BRKS-P0/1-M1
K3VL112/B-1BRMM-L0
K3VL112/B-1BRMM-L1/1-H1
K3VL112/B-1BRSS-L0
K3VL112/B-1BRWS-L0
K3VL112/B-1C4LSM-L1
K3VL112/B-1CLCM-P0/1-E0
K3VL112/B-1CLCM-P0/1-H1
K3VL112/B-1CLCS L0
K3VL112/B-1CLSM-P0
K3VL112/B-1CLWM-L0/1-H1
K3VL112/B-1CLWS-L0
K3VL112/B-1CRCM-P0/1-E0
K3VL112/B-1CRCM-P0/1-H1
K3VL112/B-1CRKS-L1
K3VL112-B-1CRSM-L0_1-H
K3VL112/B-1DRSM-P0
K3VL112/B-1NLSM-L0
K3VL112 B 1NLSS L1
K3VL112/B-1NLWM-L0
K3VL112/B-1NLXS-L1
K3VL112/B-1NRCS-L1/1-}H1
K3VL112/B-1NRCS-L1
K3VL112/B-1NRKM-L0/1-E0
K3VL112/B-1NRKM-L0/1-H1
K3VL112/B-1NRSM-L0/1-H1
K3VL112/B-1NRSS-L0-/1-M1
K3VL112/B-1NRSS-L0
K3VL112/B-1NRSS-PN24D
K3VL112/B-1NRWM-L0
K3VL112/B-1RLCM-L1
K3VL112/B-1RLSM-P0
K3VL112/B-1RLXS-L1
K3VL140/B-10}RKS-P0
K3VL140/B-10RMM-P0/1-H1
K3VL140/B-10RMM-P0
K3VL140/B-10RSS-P0/1-H2
K3VL140/B-1ALKM-P0
K3VL140/B-1ALSM-L1
K3VL140/B-1ARMM-P0/1-}E0
K3VL140/B-1ARSM-P0/1-E0
K3VL140/B-1ARSS-L0/1-H1
K3VL140/B-1BLSM-L0
K3VL140/B-1BLSM-L1/1-Q0
K3VL140/B-1BLXM-PM24D
K3VL140/B-1}BRCS-PV
K3VL140/B-1CLMM-L1
K3VL140/B-1CLSM-L0/1-H1
K3VL140/B-1CRKS-L0/1-H1
K3VL140/B-1CRSS-P0
K3VL140 B 1DLKS L1
K3VL140/B-1DLSM-L0/1-}E0
K3VL140/B-1DLSM-L1
K3VL140/B-1DRKS-L1/1-00
K3VL140/B-1DRMM-P0
K3VL140/B-1NLCM-L0
K3VL140/B-1NLCM-L1/1-}H4
K3VL140/B-1NLMM-L0
K3VL140/B-1NLSM-L1
K3VL140/B-1NLSS-P0/1-}E0
K3VL140/B-1NRKM-L0
K3VL140/B-1NRMM-L0/1-H1
K3VL140/B-1NRMM-P0
K3VL140/B-1NRMM-PM24D
K3VL140/B-1NRMM-PV/1-}E0
K3VL140/B-1NRSS-L0/1-E0
K3VL112/B-1CRWM-L0 + K3VL80/B-10}RSM-L0
K3VL112/B-1CRWM-L0/1-M1 +} K3VL80/B-10}RSM-L0
K3VL112/B-1DLSS-PN24D + K3VL112/B-1BBLSS-L{{10}} K3VL45/B-1ALSM-P0
K3VL112/B-1BBRWM-L0 + K3VL45/B-1BRSM-L0
K3VL112/B-1DRWM-L0 + K3VL112/B-1NRSM-L0
K3VL112/B-1BBRWM L0 + K3VL45/B-1NRSM-L0
K3VL112/B-1BBRSS-P0 + K3VL45/B-1BBRSS-P0 + K3VL45/B-10RSS-P0
K3VL112/B-1CLSM-L0/1-M4 + K3VL80/B-1NLSM-L0
K3VL112/B-1CLWM-L0/1-H1 + K3VL80/B-1NLSM-L0
K3VL112/B-1CRKM-P0/1-M2 + K3VL80/B-10}RSM-P0
K3VL140/B-1BBLSM-P0 + K3VL45/B-1NLSM-P0
K3VL140/B-1DLSM-L0/1-H3 + K3VL112/B-1BBLSS-P0/ 1-H3 + K3VL45/B-1NLSS-P0
K3VL140/B-1DLSM-L0/1-E0 + K3VL140/B-1NLSM-L0
K3VL140/B-1DRKS-L1/1-00 + K3VL140/B-1NRSS-L1
K3VL140/B-1DRSM-P0 + K3VL112/B-1}CRSM-P0 + K3VL80/B-10}RSM-P0
K3VL140/B-1DRSM-P0 + K3VL112/B-10}RSM-P0
K3VL200
K3VL200/B-1}ARSS-L1
K3VL200/B-1BRKM-L0/1-H2
K3VL200/B-1BRSS-L0/1-H2
K3VL200/B-10RKS-P0/1-H1
K3VL200/B-1CRKS-L0
K3VL200/B-1CRSM-L0
K3VL200/B-1DRKS-PV
K3VL200/B-1CRKS-L0
K3VL200/B-1CRSM-L0
K3VL200/B-1DRKS-PV
K3VL200/B-1DRFM-L1
K3VL200/B-1DRSS-P0/1-H1
K3VL200/B-1ELFM-L0/1-E0
K3VL200/B-1ERFM-L1/1-}H5
K3VL200/B-1ERKM-P0/1-H5
K3VL200/B-1NRSM-L1/1-}H5
K3VL200/B-1NLKM-L0
K3VL200/B-1NLSM-L0
K3VL200/B-1NLSM-L0/1-E0
K3VL200/B-1NRKM-L1
K3VL200/B-1NRSS-L0
K3VL200/B-1NRKM-P0
K3VL200/B-1NRSS-L0/1-E0
K3VL200/B-1NRSS-L0/1-H1
K3VL200/B-1NRSS-PN24D
K3VL200/B-1ERFM-L1/1-H5 + K3VL200/B-1NRSM-L1/1-H5
